Engine Model:4DX21-72/KDl2504TCR Maximum Gross Power: ISO 14396(Din) 55KW-88KW SAE J1995:55KW-88KW Bucket Capacity:0.75cube-1.5cube Full Turn Tipping Load:3405kg-3700kg Operating weight:5600kg-6560kg Tire:16/70-20-16/70-24
Maximum Gross Power:
SAE J1995:55KW-88KW
Full Turn Tipping Load:3405kg-3700kg
Tire:16/70-20-16/70-24
<p style="margin-top:0px;margin-bottom:0px;padding:0px;list-style:none;line-height:24px;color:#333333;font-family:" font-size:14px;white-space:normal;background-color:#ffffff;"="">
| mm | |
| Cab height | 3100 |
|
Ground clearance | 420 |
|
Wheelbase | 2650 |
|
Total length | 7000 |
|
Unloading distance when standard unloading height | 610 |
|
Unloading distance when the unloading height is extended | 1260 |
|
Excavation depth | 990 |
|
Standard maximum unloading height | 3875 |
|
Extend the maximum unloading height | 5000 |
|
Bucket load standard lifting height | 4530 |
|
Bucket load extended maximum height | 5655 |
|
Maximum height of the hinge pin | 5655 |
|
Standard maximum height of the hinge pin | 5880 |
|
After leaving the ground | 35degree |
|
Total length under fork condition | 7670 |
|
Loading distance | 1380 |
|
Standard maximum extension distance | 1715 |
|
Extend the maximum reach | 3015 |
| Fork depth is lower than the floor size | 1020 |
|
Ground height at the maximum extension of the fork | 1720 |
|
Fork standard maximum height | 4520 |
|
The fork extends to the maximum height | 5645 |
|
Unloading distance when the fork reaches the maximum height | 980 |
|
Turning radius outside the bucket | 7220 |
|
Turning radius inside the bucket | 4700 |
|
Bucket width | 2400 |
|
Front wheel width | 1780 |
|
Maximum width of the machine | 2290 |
|
Steering angle |
40 degree |
|
Dumping angle at maximum lift height |
40 degree |
